Features of Cast AlNiCo:
Vast range of complex shapes and sizes at an economical cost, ideal for high temperature applications up to 550℃
Good corrosion resistance density ranging from 6.9/cm3 to 7.39/cm3. A typical hardness of 50 Rockwell C, Machin-
able only by grinding;
Applications:
Automotive, Sensors and instruments, audio apparatus, electric motors, educational equipment and aerospace equipment.
Magnetic property parameters of cast Alnico
Note: Curie temperature and temperature coefficient are for reference only, but not as inspection base.
Features of Sintered AlNiCo:
Manufactured by powder metallurgical process and sintered to produce near net shapes.
Ideal for high temperature application up to 550℃.
Good corrosion resistance
Fine crystalline metallic structure, density ranging from 6.9g/cm3-7.39cm3
A typical hardness of 50 Rockwell c only suitable for grinding, individual tailored products possible.
Applications:
applied to various instruments communication control systems and sensors.
Magnetic property parameters of sintered alnico
Note: Curie temperature and temperature coefficient are for reference only, but not as inspection base.
Production Chart of Cast AlNiCo
Production Process Related Images
Production Chart of Sintered AlNiCo
Bar/Disk Magnet of Cast AlNiCo.
| Part No | Grade | Dimensions | Application | |
|---|---|---|---|---|
| A(mm) | B(mm) | |||
| 50154 | LNG40 | 1.57 | 9.525 | Micro-motors |
| 50207 | LNG40 | 1.7 | 12 | Micro-motors |
| 50007 | LNG40 | 3.175 | 12.7 | Micro-motors |
| 50260 | LNG40 | 4 | 15 | Sensors |
| 50013/50341/50008/ 50033/50012/50001 | LNG40 | 5 | 10/15/17/18/20/25.4 | Sensors |
| 52002/51025/50304 | LNG40 | 6 | 25/30/100 | Sensors |
| 50116/50058 | LNG40 | 6.35 | 25.4/31.75 | Sensors |
| 50021 | LNG40 | 7 | 30 | Sensors |
| 50264/50032/50088 /50203/50411 | LNG40 | 8 | 20/25/30/50/150 | Sensors |
| 30115 | LN10 | 9 | 5 | Sensors |
| 52053/50080/50096 | LNG40 | 9.525 | 25.4/38.1/63.5 | Sensors |
| 50366/50282/51070 /50016/503 | LNG40 | 10 | 10/12/15/30/140 | Sensors |
| 50325 | LNG52 | 10 | 28 | Sensors |
| 30107 | LN10 | 10.4 | 8 | Meters |
| 50444 | LNG40 | 11 | 50 | Sensors |
| 52006/52054 | LNG40 | 12 | 30/50 | Sensors |
| 54180/59047 | LNG40 | 12.7 | 50.8/76.2 | Cows |
| 50420/50042/54139 | LNG40 | 13 | 10/12/15 | Speakers |
| 54142 | LNG40 | 25 | 20 | Assembly |
| 54175 | LNG52 | 38 | 16 | Balances |
Block Magnet of Cast AlNiCo.
| Part No | Grade | Dimensions | Applications | ||
|---|---|---|---|---|---|
| A（mm) | B(mm) | C(mm) | |||
| 3223 | LN10 | 23 | 4 | 6 | Odometers |
| 3224 | LN10 | 25 | 5 | 6 | Odometers |
| 3225 | LN10 | 23 | 3.5 | 6 | Odometers |
| 20001 | LNG13 | 51 | 5 | 5 | Meters |
| 20005 | LNG13 | 218 | 10 | 146 | Port Machines |
| 38103 | LN10 | 142 | 9 | 70 | Port Machines |
| 58046 | LNG40 | 101.6 | 40 | 76.2 | Speakers |
| 58048 | LNG40 | 50.8 | 25.4 | 38.1 | Motors |
| 58337 | LNG40 | 101.6 | 38.1 | 76.2 | Speakers |
Ring Magnet of Cast AlNiCo
| Part No | Grade | Dimensions | Application | ||||
|---|---|---|---|---|---|---|---|
| A | B | C | D | E | |||
| 57003 | LNG37 | 42 | 20 | 30 | 10 | Blenders | |
| 57012 | LNG37 | 55 | 11 | 13.4 | 16 | Meters | |
| 57036 | LNG37 | 28.6 | 7.6 | 25.4 | 8 | Education | |
| 57038 | LNG37 | 30 | 20 | 20 | 7.5 | D5 | Holding |
| 57039 | LNG37 | 45 | 30 | 30 | 11 | D5 | Holding |
| 57040 | LNG37 | 25.4 | 15.9 | 5.6 | D4.8 | Holding | |
| 57041 | LNG37 | 19.05 | 12.7 | 5.6 | D4.8 | Holding | |
| 57042 | LNG37 | 31.75 | 25.4 | 7.94 | D7.1 | Holding | |
| 57044 | LNG37 | 40 | 25 | 25 | 10 | Holding | |
| 57122 | LNG37 | 39.6 | 25.4 | 25.4 | 10.3 | D5.5 | Holding |
| 57131 | LNG37 | 63.5 | 47.6 | 46 | 14.3 | D4.8 | Holding |
| 57136 | LNG37 | 69.8 | 57.1 | 41.3 | 14.3 | 2XD7.9 | Holding |
| 57167 | LNG37 | 64 | 12 | 26 | 14 | Holding | |
| 57187 | LNG37 | 17 | 22 | 10 | 6.25 | Meters | |
| 57197 | LNG37 | 62 | 26 | 61 | 13 | Education | |
| 57250 | LNG37 | 21 | 13.1 | 16.2 | 6.2 | Meters | |
Horseshoe Magnet of Cast AlNiCo
| Part No | Grade | Dimensions | Application | |||
|---|---|---|---|---|---|---|
| A | B | C | D | |||
| 56007 | LNG37 | 63.5 | 12.7 | 3.175 | Musical Instruments | |
| 56008 | LNG37 | 58 | 12.6 | 3 | Musical Instruments | |
| 56022 | LNG37 | 60 | 12.7 | 3 | Musical Instruments | |
| 56032 | LNG37 | 25.4 | 6.35 | 6.35 | Sensors | |
| 56089 | LNG37 | 22.5 | 4.3 | 4.3 | Sensors | |
| 56099 | LNG44 | 69 | 25 | 25 | 15 | Magnetic Chucks |
| 56101 | LNG37 | 62 | 13 | 3 | Musical Instruments | |
| 56109 | LNG40 | 75 | 15 | 10 | Education | |
| 56111 | LNG37 | 19 | 3.2 | 3.2 | Sensors | |
| 56133 | LNG37 | 150 | 16 | 6 | Education | |
| 56190 | LNG40 | 25 | 22.5 | 7 | Meters | |
| 56191 | LNG40 | 25 | 22 | 7 | R4 | Meters |
| 56226 | LNG40 | 42 | 42 | 20 | 6.5 | Magnetic Chucks |
| 56306 | LNG37 | 45 | 20 | 15 | 7 | Magnetic Chucks |
| 56328 | LNG37 | 50 | 20 | 20 | 7 | Magnetic Chucks |
| 90017 | LNGT72 | 50 | 50 | 40 | Magnetic Chucks | |
| 56369 | LNG52 | 45 | 24 | 15 | Magnetic Chucks | |
| 56382 | LNG52 | 45 | 22.5 | 15 | Magnetic Chucks | |
| 56252 | LNG44 | 59.5 | 59.5 | 25 | 11 | Magnetic Chucks |
| 59179 | LNG40 | 45 | 18.5 | 30.5 | Magnetic Bases | |
| 59154 | LNG40 | 53 | 19.3 | 32 | Magnetic Bases | |
